┌───────────────────────┐ ▄▄▄▄▄ ▄▄▄▄▄ ▄▄▄▄▄ │ │ █ █ █ █ █ █ │ │ █ █ █ █ █▀▀▀▀ │ │ █ █ █ █ ▄ │ │ ▄▄▄▄▄ │ │ █ █ │ │ █ █ │ │ █▄▄▄█ │ │ ▄ ▄ │ │ █ █ │ │ █ █ │ │ █▄▄▄█ │ │ ▄▄▄▄▄ │ │ █ │ phork: Packing SHELF Back Into One ELF │ █ │ ~ TMZ └───────────────────█ ──┘ phork │ ├── phork.asm ├── utils.inc ├── Makefile │ ├── utils │ │ │ ├── mkpack.asm │ ├── spack_tool.asm │ └── tools.inc │ ├── test │ │ │ ├── test.c │ ├── test_argv_tls.c │ ├── payload_asm.asm │ └── static-pie.ld │ └── loader │ ├── reloc.inc ├── stack.inc ├── rwdata.inc └── rodata.inc Download phork.tgz -= The Half-Loader Series: 3/3 This article is the third and final part of a three part series for tmp.0ut volume 5: 1. halfexec A broad userspace ELF loader and the baseline runtime machinery. 2. halfshelf A one PT_LOAD structure and a detached headless representation. 3. phork (you are here) A normal stub ELF carrying that metadata and stripped representation. Arguably the most interesting article of the bunch. -= Introduction phork is my attempt at a (overcomplicated?) SHELF packer. It takes a SHELF payload, removes its ELF header and Program Header Table from the stored body, packs the missing facts beside it, then glues the whole thing to a small FASM loader. The output is still one normal executable. Linux starts the loader at the front. The loader opens its own file, fishes the payload out of the tail, rebuilds the runtime image and jumps into it. In short: it's a self extracting/self loading executable packer. It packs a binary, and the stub unpacks and runs it in-memory at execution time with no temp files. -= The Payload The packer is strict, so a payload must be: - x64 and little-endian - ET_DYN - statically linked with no PT_INTERP - exactly one PT_LOAD - PT_LOAD.p_offset == 0 - PT_LOAD.p_vaddr == 0 - optionally described by PT_DYNAMIC - optionally described by PT_TLS The zero offset and zero virtual address rules make the chosen mapping base the load bias. Every payload virtual address becomes a simple addition and there is no segment placement puzzle hiding in the loader. One segment also means one final protection mask. This is not the prettiest W^X story because merged code and data can require broad permissions. It is a trade made for a loader that stays small enough to understand without incense. -= Pack Time, Where The Head Goes The builder parses the source ELF and calculates: header_span = e_phoff + e_phnum * e_phentsize That span covers the ELF header area through the final Program Header entry. The stored payload starts at header_span and ends at the original PT_LOAD.p_filesz. Nothing after the Program Header Table is shifted inside the logical image. Those bytes are only sliced out for storage. At runtime they go back to: mapped_base + header_span This is why addresses inside the payload do not need a second adjustment. Their image offsets remain exactly where the linker placed them. The bytes that were removed are replaced by a compact record named SHELFBN1. It stores the fields required to recreate the image and a raw copy of the original Program Header Table. -= Two Formats, Two Jobs The final file is: [stub ELF][SHELFBN1 metadata][stripped payload][SPACK01! footer] The two format layers are: - SPACK01! says where the embedded objects are in this file - SHELFBN1 says how the payload must look in memory The outer footer knows storage offsets while the inner record knows ELF semantics. -= The SPACK Footer The last 48 bytes are always plain and fixed size: offset size field 0x00 8 "SPACK01!" 0x08 8 meta_off 0x10 8 meta_len 0x18 8 payload_off 0x20 8 payload_len 0x28 8 flags All integers are little-endian unsigned 64 bit values. Starting at EOF makes discovery cheap. The loader only needs the file size and one pread64 to find everything else. Current flags are: - 0x01 XOR the metadata with 0xA5 - 0x02 XOR the payload with 0xA5 - 0x04 RLE encode the payload The stub's runtime side understands all three: it will de-XOR either blob and run the RLE decoder before touching anything else. mkpack can set the first two on request, with --xor-meta and --xor-payload, applied in any order after the three required paths. The XOR itself buys nothing against a motivated individual, it is a fixed single byte key, but it does exercise the exact same flag bit and decode path a real transform would use. RLE stays decode only for now. Writing a correct encoder against the token format described below felt like its own small project, so it is a candidate for a later revision. -= Inside SHELFBN1 The record starts with SHELFBN1, then 17 little-endian 64 bit fields, then the original Program Header bytes: entry original e_entry phoff original e_phoff phnum number of Program Headers phentsize size of one Program Header header_span byte count removed from the front load_offset required to be zero load_vaddr required to be zero load_filesz file size of PT_LOAD load_memsz full in-memory size of PT_LOAD load_flags_num translated mmap protection bits dynamic_vaddr PT_DYNAMIC virtual address, or zero dynamic_memsz PT_DYNAMIC size, or zero tls_vaddr TLS initializer virtual address, or zero tls_filesz initialized TLS byte count tls_memsz complete TLS block size tls_align required TLS alignment phdr_blob_size size of the Program Header copy phdr_blob original Program Header bytes The loader requires phdr_blob_size == phnum * phentsize. It also checks that the metadata has enough bytes and that load_filesz is not smaller than header_span. The stripped payload size is computed as load_filesz - header_span, unsigned. Skip the check and a crafted SHELFBN1 record with header_span > load_filesz underflows that subtraction into a number near 2^64, which then gets handed straight to the RLE decoder as its expected output size, defeating the decoder's own bounds checking in the process. This loader validates its own metadata for exactly that reason, an attacker controls the sidecar just as much as the payload, and the two are trusted only after they reach consensus. -= Bootstrapping From The Tail When Linux executes the packed file, it only cares about the stub ELF at the front. Appended data is outside the stub load image, but still part of the file. The stub begins on the original kernel stack and saves argc, argv, envp and the executable path. It then opens /proc/self/exe. This is better than trusting argv[0], which can be relative, renamed or simply a lie supplied by the caller. The runtime path is: 1. read the 48 byte footer from EOF 2. validate magic, flags, lengths and non-overlap 3. load and optionally de-XOR SHELFBN1 4. parse its fixed fields and copy the saved Program Headers 5. load the stored payload 6. de-XOR it before RLE decoding when both flags are active 7. require the decoded size to equal load_filesz - header_span 8. reserve the image, rebuild its head and copy its body 9. apply relocations, create TLS and rebuild the process stack 10. switch rsp and jmp to base + entry The packed file never becomes the payload through a second kernel execution. The stub performs the missing loader work inside the current process. -= RLE Without Drama The RLE stream has 1 byte control tokens and bit 7 chooses the token type. Thelower seven bits store a count minus one, giving lengths from 1 through 128. - bit 7 clear means copy the next count bytes literally - bit 7 set means repeat the next byte count times The decoder receives the exact expected output size from SHELFBN1. It rejects a stream that ends early, reads past its input or expands past the expected payload length. Worked by hand, encoding the 12 bytes "AAAAAAAABCDE" (eight As, then four literal bytes) looks like this: input: 41 41 41 41 41 41 41 41 42 43 44 45 (12 bytes) tokens: 87 41 (run: 0x80|(8-1), value 'A') 03 42 43 44 45 (literal: 0x00|(4-1), then "BCDE") output: 7 bytes on disk for 12 bytes in memory 0x87 has bit 7 set, so it is a run token: 0x87 & 0x7f = 7, plus one, is a count of 8, followed by the single repeated byte. 0x03 has bit 7 clear, so it is a literal token: count 4, followed by the 4 literal bytes themselves. It will not beat a real compressor. It will eat runs of zeroes nicely and the decoder fits the project. -= Rebuilding The Image The loader rounds load_memsz up to a page boundary and creates one anonymous read write mapping. Anonymous pages start zeroed, so the region after load_filesz naturally becomes the BSS tail. At the mapping base it writes a synthetic Elf64_Ehdr. The stable identity fields are filled locally, including ELF64, little-endian, x64 and ET_DYN. Values such as entry point, Program Header offset, count and entry size come from SHELFBN1. The saved Program Header bytes are copied to base + phoff and the decoded payload follows at base + header_span. The resulting image is logically equivalent to the input load segment: base + 0 synthetic ELF header base + phoff restored Program Header Table base + header_span original bytes after the table base + load_filesz start of zero filled tail base + load_memsz logical end of the image After population, mprotect applies the permissions captured from the original PT_LOAD. The loader then sets AT_PHDR to the restored table inside this mapping. -= Relocations Before Entry Position independent does not mean every pointer arrives ready as static PIE images usually contain relative relocations that must use the chosen load bias. If PT_DYNAMIC exists, the loader walks its Elf64_Dyn entries and collects DT_RELA, DT_RELASZ, DT_RELAENT, DT_JMPREL, DT_PLTRELSZ and DT_PLTREL. The supported relocation set is: - R_X86_64_RELATIVE writes base + addend to base + offset - R_X86_64_IRELATIVE calls the resolver at base + addend and writes its return value to base + offset Plain relative relocations run first. Indirect resolvers run in a second pass, after the pointers they may depend on are already fixed. The same two passes cover the main RELA table and JMPREL. Anything outside that small world is rejected. Supporting symbols, shared objects and a real interpreter would turn this into a different beast. I have enough hobbies already (mid life crisis?). -= TLS, The Part That Bites A static PIE may carry PT_TLS even without PT_INTERP. Jumping directly to its entry point means no dynamic linker will prepare thread local storage so the stub must do it. phork normalizes the requested alignment to at least 16 bytes, then maps space for three objects: [TLS block][TCB][small DTV] It copies tls_filesz initializer bytes from base + tls_vaddr, zeroes the remainder through tls_memsz, places an aligned Thread Control Block after the TLS area and seeds a tiny Dynamic Thread Vector for one module. Finally arch_prctl(ARCH_SET_FS) points the x64 FS base at that TCB. Now the payload can execute the usual FS relative TLS accesses without finding an empty void where its thread pointer should be. -= A Fresh Kernel Stack The payload should see a process entry stack, not the loader's half used work area. The stub allocates a new stack mapping and rebuilds this layout: argc argv pointers NULL envp pointers NULL auxiliary vector Argument and environment strings are copied into target storage. The 16 bytes behind AT_RANDOM are copied too, along with strings referenced by AT_PLATFORM and AT_BASE_PLATFORM. Most auxv entries survive unchanged. Image values are patched: - AT_PHDR points to base + phoff - AT_PHENT and AT_PHNUM match the reconstructed table - AT_ENTRY becomes base + entry - AT_BASE is zero because there is no interpreter - AT_EXECFN points to the copied executable path Once the tables and strings are placed, the stack pointer is aligned for the x64 entry ABI. The loader closes its self file descriptor, installs the new rsp and jumps straight into the mapped entry point. -= Why Not Embed The Full ELF That would work, of course. It would also dodge the most interesting thing to me. Embedding a complete ELF preserves a parser friendly wrapper that the runtime already knows how to recreate. Stripping the prefix makes the storage format explicit: - executable bytes stay executable bytes - ELF facts become SHELFBN1 - packed file locations become SPACK01! This is not a universal compression win. The stub and metadata have their own cost but the win is architectural. Each layer carries only the facts its consumer needs, and the final output remains one directly executable file. -= Tooling, Because One Builder Was Too Peaceful The archive contains code for building the pack, and separate tools for inspection, validation and extraction. For packing: utils/mkpack.asm

    mkpack <stub-elf> <input-shelf-elf> <output-packed> [--xor-meta] [--xor-payload]

The two flags are independent and order does not matter. Leaving both off is still the default, and produces the exact same flags = 0 pack as before. For looking inside, validating or extracting a pack: utils/spack_tool.asm They are also written in FASM. A quick look at both flags landing on the same pack, using the argv/TLS sample:

$ mkpack ./phork input_tls packed --xor-meta --xor-payload
$ spack_tool inspect packed
spack magic: SPACK01!
file_size: 727171
footer_off: 727123
meta_off: 7907
meta_len: 312
payload_off: 8219
payload_len: 718904
flags: 3
$ ./packed alpha beta; echo $?
argv/tls ok 20
7

flags = 3 is 0x01 | 0x02, both bits landed, and the packed file still runs exactly like the unflagged one. The de-XOR happens before anything else touches the embedded bytes, so correctness never depended on it. -= Samples And Running It The tarball also includes some sample binaries that are tailored to work with the packer.

$ PHORK_DEBUG=1 make run
...
spack: self loading SHELF packer stub
phork: debug tracing enabled
phork: reserving SHELF load window
phork: load bias = 0x000075d18f306000
phork: mapping SHELF PT_LOAD at 0x000075d18f306000
phork: synthetic stack base = 0x000075d18ea00000
phork: applying direct entry relocations
phork: preparing PT_TLS runtime state
phork: rebuilding argc/argv/envp/auxv
phork: jumping to SHELF entry = 0x000075d18f30ccc0
hello
...

-= Final Thoughts The original SHELF work asks a beautiful question. If static PIE already knows how to live anywhere, how much ELF can we remove before it stops being a "real" program. Despite having conscious design limits, it asks: "Can the stripped thing carry its own loader and still arrive as one normal executable?" --- Phork Turns out you can, little phorky. (no DMCA plz Mickey) -= References [1] Introducing SHELF Loading, tmp.0ut volume 1 [2] SHELF Loading by @ulexec [3] The Design and Implementation of Userland Exec [4] GNU ld PHDRS documentation [5] halfexec: Assembly x64 ELF Linux Loader, tmp.0ut volume 5 [6] halfshelf: Loading ELF After The Header Is Gone, tmp.0ut volume 5 --[ PREV | HOME | NEXT ]--
